Description

Virtual Instrument extension of the AAX_CEffectParameters class.

This extension to AAX_CEffectParameters adds some Virtual Instrument (VI) conveniences:

The RenderAudio method provides a direct audio processing callback within the data model object. Perform all audio processing in this method.
The StaticDescribe method establishes a generic MIDI processing context for the Effect. Call this method from the plug-in's Description callback implementation.

Note: This convenience class assumes a monolithic processing environment (i.e. AAX_eConstraintLocationMask_DataModel .) This precludes the use of AAX_CInstrumentParameters -derived Effects in distributed-processing formats such as AAX DSP.

Public Member Functions
	AAX_CInstrumentParameters (void)

virtual	~AAX_CInstrumentParameters (void)

Render Functions
virtual functions to override when you want to generate audio output.
virtual void	RenderAudio (AAX_SInstrumentRenderInfo *ioRenderInfo)

Public Member Functions inherited from AAX_CEffectParameters
	AAX_CEffectParameters (void)

virtual	~AAX_CEffectParameters (void)

AAX_CEffectParameters &	operator= (const AAX_CEffectParameters &other)

virtual AAX_Result	Initialize (IACFUnknown *iController)
	Main data model initialization. Called when plug-in instance is first instantiated. More...

virtual AAX_Result	Uninitialize (void)
	Main data model uninitialization. More...

virtual AAX_Result	NotificationReceived (AAX_CTypeID iNotificationType, const void *iNotificationData, uint32_t iNotificationDataSize)
	Notification Hook. More...

virtual AAX_Result	GetNumberOfParameters (int32_t *oNumControls) const
	CALL: Retrieves the total number of plug-in parameters. More...

virtual AAX_Result	GetMasterBypassParameter (AAX_IString *oIDString) const
	CALL: Retrieves the ID of the plug-in's Master Bypass parameter. More...

virtual AAX_Result	GetParameterIsAutomatable (AAX_CParamID iParameterID, AAX_CBoolean *oAutomatable) const
	CALL: Retrieves information about a parameter's automatable status. More...

virtual AAX_Result	GetParameterNumberOfSteps (AAX_CParamID iParameterID, int32_t *oNumSteps) const
	CALL: Retrieves the number of discrete steps for a parameter. More...

virtual AAX_Result	GetParameterName (AAX_CParamID iParameterID, AAX_IString *oName) const
	CALL: Retrieves the full name for a parameter. More...

virtual AAX_Result	GetParameterNameOfLength (AAX_CParamID iParameterID, AAX_IString *oName, int32_t iNameLength) const
	CALL: Retrieves an abbreviated name for a parameter. More...

virtual AAX_Result	GetParameterDefaultNormalizedValue (AAX_CParamID iParameterID, double *oValue) const
	CALL: Retrieves default value of a parameter. More...

virtual AAX_Result	SetParameterDefaultNormalizedValue (AAX_CParamID iParameterID, double iValue)
	CALL: Sets the default value of a parameter. More...

virtual AAX_Result	GetParameterType (AAX_CParamID iParameterID, AAX_EParameterType *oParameterType) const
	CALL: Retrieves the type of a parameter. More...

virtual AAX_Result	GetParameterOrientation (AAX_CParamID iParameterID, AAX_EParameterOrientation *oParameterOrientation) const
	CALL: Retrieves the orientation that should be applied to a parameter's controls. More...

virtual AAX_Result	GetParameter (AAX_CParamID iParameterID, AAX_IParameter **oParameter)
	CALL: Retrieves an arbitrary setting within a parameter. More...

virtual AAX_Result	GetParameterIndex (AAX_CParamID iParameterID, int32_t *oControlIndex) const
	CALL: Retrieves the index of a parameter. More...

virtual AAX_Result	GetParameterIDFromIndex (int32_t iControlIndex, AAX_IString *oParameterIDString) const
	CALL: Retrieves the ID of a parameter. More...

virtual AAX_Result	GetParameterValueInfo (AAX_CParamID iParameterID, int32_t iSelector, int32_t *oValue) const
	CALL: Retrieves a property of a parameter. More...

virtual AAX_Result	GetParameterValueFromString (AAX_CParamID iParameterID, double *oValue, const AAX_IString &iValueString) const
	CALL: Converts a value string to a value. More...

virtual AAX_Result	GetParameterStringFromValue (AAX_CParamID iParameterID, double iValue, AAX_IString *oValueString, int32_t iMaxLength) const
	CALL: Converts a normalized parameter value into a string representing its corresponding real value. More...

virtual AAX_Result	GetParameterValueString (AAX_CParamID iParameterID, AAX_IString *oValueString, int32_t iMaxLength) const
	CALL: Retrieves the value string associated with a parameter's current value. More...

virtual AAX_Result	GetParameterNormalizedValue (AAX_CParamID iParameterID, double *oValuePtr) const
	CALL: Retrieves a parameter's current value. More...

virtual AAX_Result	SetParameterNormalizedValue (AAX_CParamID iParameterID, double iValue)
	CALL: Sets the specified parameter to a new value. More...

virtual AAX_Result	SetParameterNormalizedRelative (AAX_CParamID iParameterID, double iValue)
	CALL: Sets the specified parameter to a new value relative to its current value. More...

virtual AAX_Result	TouchParameter (AAX_CParamID iParameterID)
	"Touches" (locks) a parameter in the automation system to a particular control in preparation for updates More...

virtual AAX_Result	ReleaseParameter (AAX_CParamID iParameterID)
	Releases a parameter from a "touched" state. More...

virtual AAX_Result	UpdateParameterTouch (AAX_CParamID iParameterID, AAX_CBoolean iTouchState)
	Sets a "touched" state on a parameter. More...

virtual AAX_Result	UpdateParameterNormalizedValue (AAX_CParamID iParameterID, double iValue, AAX_EUpdateSource iSource)
	Updates a single parameter's state to its current value. More...

virtual AAX_Result	UpdateParameterNormalizedRelative (AAX_CParamID iParameterID, double iValue)
	Updates a single parameter's state to its current value, as a difference with the parameter's previous value. More...

virtual AAX_Result	GenerateCoefficients (void)
	Generates and dispatches new coefficient packets. More...

virtual AAX_Result	GetNumberOfChunks (int32_t *oNumChunks) const
	Retrieves the number of chunks used by this plug-in. More...

virtual AAX_Result	GetChunkIDFromIndex (int32_t iIndex, AAX_CTypeID *oChunkID) const
	Retrieves the ID associated with a chunk index. More...

virtual AAX_Result	GetChunkSize (AAX_CTypeID iChunkID, uint32_t *oSize) const
	Get the size of the data structure that can hold all of a chunk's information. More...

virtual AAX_Result	GetChunk (AAX_CTypeID iChunkID, AAX_SPlugInChunk *oChunk) const
	Fills a block of data with chunk information representing the plug-in's current state. More...

virtual AAX_Result	SetChunk (AAX_CTypeID iChunkID, const AAX_SPlugInChunk *iChunk)
	Restores a set of plug-in parameters based on chunk information. More...

virtual AAX_Result	CompareActiveChunk (const AAX_SPlugInChunk iChunkP, AAX_CBoolean oIsEqual) const
	Determine if a chunk represents settings that are equivalent to the plug-in's current state. More...

virtual AAX_Result	GetNumberOfChanges (int32_t *oNumChanges) const
	Retrieves the number of parameter changes made since the plug-in's creation. More...

virtual AAX_Result	TimerWakeup ()
	Periodic wakeup callback for idle-time operations. More...

virtual AAX_Result	GetCurveData (AAX_CTypeID iCurveType, const float iValues, uint32_t iNumValues, float oValues) const
	Generate a set of output values based on a set of given input values. More...

virtual AAX_Result	GetCustomData (AAX_CTypeID iDataBlockID, uint32_t iDataSize, void oData, uint32_t oDataWritten) const
	An optional interface hook for getting custom data from another module. More...

virtual AAX_Result	SetCustomData (AAX_CTypeID iDataBlockID, uint32_t iDataSize, const void *iData)
	An optional interface hook for setting custom data for use by another module. More...

virtual AAX_Result	DoMIDITransfers ()
	MIDI update callback. More...

virtual AAX_Result	UpdateMIDINodes (AAX_CFieldIndex iFieldIndex, AAX_CMidiPacket &iPacket)
	MIDI update callback. More...

virtual AAX_Result	UpdateControlMIDINodes (AAX_CTypeID nodeID, AAX_CMidiPacket &iPacket)
	MIDI update callback for control MIDI nodes. More...

virtual AAX_Result	RenderAudio_Hybrid (AAX_SHybridRenderInfo *ioRenderInfo)
	Hybrid audio render function. More...

AAX_IController *	Controller ()
	Access to the Effect controller. More...

const AAX_IController *	Controller () const
	`const` access to the Effect controller More...

AAX_ITransport *	Transport ()
	Access to the Transport object. More...

const AAX_ITransport *	Transport () const
	`const` access to the Transport object More...

AAX_IAutomationDelegate *	AutomationDelegate ()

const AAX_IAutomationDelegate *	AutomationDelegate () const

Public Member Functions inherited from AAX_IEffectParameters
ACFMETHOD()	InternalQueryInterface (const acfIID &riid, void **ppvObjOut)

Hybrid audio methods
MIDI methods
Initialization and uninitialization
AAX host and plug-in event notification
Parameter information
These methods are used by the AAX host to retrieve information about the plug-in's data model. For information about adding parameters to the plug-in and otherwise modifying the plug-in's data model, see AAX_CParameterManager. For information about parameters, see AAX_IParameter.
Parameter setters and getters
These methods are used by the AAX host and by the plug-in's UI to retrieve and modify the values of the plug-in's parameters. Note The parameter setters in this section may generate asynchronous requests.
Automated parameter helpers
These methods are used to lock and unlock automation system 'resources' when updating automatable parameters. Note You should never need to override these methods to extend their behavior beyond what is provided in AAX_CEffectParameters and AAX_IParameter Todo: Do these methods belong in the data model? Should integration with automation system be bolt-on or otherwise modular?
Asynchronous parameter update methods
These methods are called by the AAX host when parameter values have been updated. They are called by the host and can be triggered by other plug-in modules via calls to AAX_IParameter's `SetValue` methods, e.g. SetValueWithFloat() These methods are responsible for updating parameter values. Do not call these methods directly! To ensure proper synchronization and to avoid problematic dependency chains, other methods (e.g. SetParameterNormalizedValue()) and components (e.g. AAX_IEffectGUI) should always call a `SetValue` method on AAX_IParameter to update parameter values. The `SetValue` method will properly manage automation locks and other system resources.
State reset handlers
Chunk methods
These methods are used to save and restore collections of plug-in state information, known as chunks. Chunks are used by the host when saving or restoring presets and session settings and when providing "compare" functionality for plug-ins. The default implementation of these methods in AAX_CEffectParameters provides save and restore functionality for all of the plug-in's registered parameters. Override these methods to provide additional plug-in state details that are not encapsulated by the plug-in's set of parameters. For reference, see also: AAX_CChunkDataParser AAX_SPlugInChunk
Thread Methods
EUCON Methods
Custom Data Methods
These functions exist as a proxiable way to move data between different modules (e.g. AAX_IEffectParameters and AAX_IEffectGUI.) Using these, the GUI can query any data through GetCustomData() with a plug-in defined `typeID`, `void*` and size. This has an advantage over just sharing memory in that this function can work as a remote proxy as we enable those sorts of features later in the platform. Likewise, the GUI can also set arbitrary data on the data model by using the SetCustomData() function with the same idea. Note These are plug-in internal only. They are not called from the host right now, or likely ever.
MIDI methods
Public Member Functions inherited from IACFUnknown
virtual BEGIN_ACFINTERFACE ACFRESULT ACFMETHODCALLTYPE	QueryInterface (const acfIID &iid, void **ppOut)=0
	Returns pointers to supported interfaces. More...

virtual acfUInt32 ACFMETHODCALLTYPE	AddRef (void)=0
	Increments reference count. More...

virtual acfUInt32 ACFMETHODCALLTYPE	Release (void)=0
	Decrements reference count. More...

Convenience Layer Methods
Note You should not need to override these methods, but if you do, make sure to call into the base class.
virtual AAX_Result	ResetFieldData (AAX_CFieldIndex iFieldIndex, void *oData, uint32_t iDataSize) const

static AAX_Result	StaticDescribe (AAX_IEffectDescriptor *ioDescriptor, const AAX_SInstrumentSetupInfo &setupInfo)

static void AAX_CALLBACK	StaticRenderAudio (AAX_SInstrumentRenderInfo const inInstancesBegin[], const void inInstancesEnd)

Additional Inherited Members
Protected Member Functions inherited from AAX_CEffectParameters
void	BuildChunkData (void) const
	Clears out the current chunk in Chunk Parser and adds all of the new values. Used by default implementations of GetChunk() and GetChunkSize(). More...

AAX_Result	SetTaperDelegate (AAX_CParamID iParameterID, AAX_ITaperDelegateBase &iTaperDelegate, bool iPreserveValue)

AAX_Result	SetDisplayDelegate (AAX_CParamID iParameterID, AAX_IDisplayDelegateBase &iDisplayDelegate)

bool	IsParameterTouched (AAX_CParamID iParameterID) const

bool	IsParameterLinkReady (AAX_CParamID inParameterID, AAX_EUpdateSource inSource) const

virtual AAX_Result	EffectInit (void)
	Initialization helper routine. Called from AAX_CEffectParameters::Initialize. More...

void	FilterParameterIDOnSave (AAX_CParamID controlID)
	CALL: Indicates the indices of parameters that should not be saved in the default AAX_CEffectParameters chunk. More...

Protected Attributes inherited from AAX_CEffectParameters
int32_t	mNumPlugInChanges

int32_t	mChunkSize

AAX_CChunkDataParser	mChunkParser

int32_t	mNumChunkedParameters

AAX_CBoolean	mClipped
	Set by SetClipped() and returned by GetClipped(). More...

AAX_CPacketDispatcher	mPacketDispatcher

AAX_CParameterManager	mParameterManager

std::set< std::string >	mFilteredParameters

Constructor & Destructor Documentation

AAX_CInstrumentParameters::AAX_CInstrumentParameters ( void )

virtual AAX_CInstrumentParameters::~AAX_CInstrumentParameters ( void )

virtual

Member Function Documentation

virtual void AAX_CInstrumentParameters::RenderAudio ( AAX_SInstrumentRenderInfo * ioRenderInfo )

virtual

virtual AAX_Result AAX_CInstrumentParameters::ResetFieldData	(	AAX_CFieldIndex	iFieldIndex,
		void *	oData,
		uint32_t	iDataSize
	)		const

virtual

Overridden from AAX_CEffectParameters.

Reimplemented from AAX_CEffectParameters.

static AAX_Result AAX_CInstrumentParameters::StaticDescribe	(	AAX_IEffectDescriptor *	ioDescriptor,
		const AAX_SInstrumentSetupInfo &	setupInfo
	)

static

This method performs all of the basic context setup and pointer passing work. Call this from Describe.

static void AAX_CALLBACK AAX_CInstrumentParameters::StaticRenderAudio	(	AAX_SInstrumentRenderInfo *const	inInstancesBegin[],
		const void *	inInstancesEnd
	)

static

Static RenderAudio ( This version would only work for non-distributed algorithms. )

The documentation for this class was generated from the following file:

AAX_CInstrumentParameters.h
